1997-2002 Ford Puma Service and Repair Manual

1997-2002 Ford Puma Service and Repair Manual

0 Reviews

Price: $24.99

Overview

This factory Service and Repair Manual for the 1997-2002 Ford Puma provides comprehensive technical specifications, diagnostic procedures, troubleshooting information, and step-by-step repair instructions. It covers all major vehicle systems, powertrain variants, transmission options, and electronic control systems available for this model year.

The manual includes complete mechanical repair procedures, electrical wiring diagrams, diagnostic trouble code (DTC) troubleshooting, transmission service information, braking system repairs, and central timer/immobilizer diagnostics.

Whether you are a professional technician, workshop owner, automotive student, or DIY enthusiast, this manual provides the information needed to diagnose, service, maintain, and repair the 1997-2002 Ford Puma.

What you get;

✓ Genuine factory workshop manual
✓ Comprehensive diagnostic procedures
✓ Complete wiring diagrams
✓ Covers all major systems and components
✓ We review every manual to ensure it’s genuine and safe for download
Note: This is a software download and will require installation of the OVA file.
Category:

This 1997-2002 Ford Puma Service and Repair Manual Covers

Engine and Drivetrain

  • Complete repair procedures for the 16-valve Sigma/Zetec-SE inline-4 engines (1.4L, 1.6L, 1.7L VCT, and Tickford-tuned 1.7L)
  • Electronic multipoint fuel injection system diagnostics and repair procedures
  • Variable Camshaft Timing (VCT) system service specifications for the 1.7L variant
  • Engine cooling system and mechanical water pump service specifications
  • Exhaust and emissions control system repairs including catalytic converter and oxygen sensor maintenance
  • Transmission overhaul and troubleshooting procedures for the IB5 close-ratio 5-speed manual gearbox
  • Driveshaft, constant velocity (CV) joints, and front-wheel-drive axle service procedures

Chassis and Suspension

  • Front MacPherson strut suspension repair procedures specific to the Ford Mark 4 Fiesta platform
  • Rear twist-beam suspension and uprated damper repair procedures
  • Power-assisted rack and pinion steering system diagnostics and service specifications
  • Wheel alignment specifications and manual tracking adjustment procedures
  • Front and rear wheel bearing replacement procedures
  • Suspension bushing, anti-roll bar, and track control arm diagnostics

Braking Systems

  • Teves ABS diagnostic and hydraulic actuator procedures
  • Brake hydraulic system bleed and service specifications
  • Front disc brake caliper and pad replacement procedures
  • Rear self-adjusting drum brake shoes and wheel cylinder repairs (disc setup for Racing Puma)
  • Cable-operated parking brake service and mechanical adjustment procedures
  • Brake master cylinder and vacuum servo inspection and replacement procedures

Electrical and Wiring

  • Complete factory wiring diagrams and chassis ground point locations
  • Battery load testing, alternator charging, and starter motor system diagnostics
  • Central Timer Module (CTM) and EEC-V engine management diagnostics
  • Power distribution box, passenger fuse box schematics, and relay layouts
  • Exterior lighting, analog dashboard cluster, and indicator diagnostics
  • Factory Ford audio units, analog clock, and Passive Anti-Theft System (PATS) immobilizer troubleshooting

Air Conditioning and HVAC

  • Manual climate control and cable-driven heater matrix diagnostics
  • Blower motor, resistor pack, and HVAC component replacement procedures
  • R134a refrigerant specifications, capacity, and system evacuation/charging procedures
  • Heating, ventilation, and air recirculation flap troubleshooting

Body and Interior

  • Interior door card, center console, and sport seat removal and installation procedures
  • Exterior body repair information, underbody rust prevention, and panel alignment
  • Electric window lifter, manual sunroof, and central locking system diagnostics
  • Hatchback gas strut and mechanical tailgate latch repairs
  • Drivers-side airbag and seatbelt pyrotechnic pretensioner restraint system service procedures

Diagnostics and Troubleshooting

  • Ford EEC-V Diagnostic Trouble Code (DTC) lookup procedures
  • Star tester and Ford FDS2000 / WDS tool hookup and scan tool procedures
  • Component voltage, resistance, and reference testing specifications
  • Step-by-step troubleshooting workflows for engine hesitation, rough idle, and stalling
  • Powertrain Control Module (PCM) diagnostic pinout procedures

Common Error Codes Covered

This manual provides diagnostic and repair procedures for thousands of manufacturer-specific fault codes, including:

Engine Codes

  • P0102: Mass Air Flow (MAF) sensor circuit low input
  • P0113: Intake Air Temperature (IAT) sensor circuit high input
  • P0133: Heated Oxygen Sensor (HO2S) circuit slow response (Bank 1, Sensor 1)
  • P0340: Camshaft Position (CMP) sensor circuit malfunction
  • P1390: Variable Camshaft Timing (VCT) circuit malfunction / timing solenoid fault

Transmission Codes

  • P0704: Clutch switch input circuit malfunction (IB5 manual starter interlock)
  • P0500: Vehicle Speed Sensor (VSS) circuit malfunction (gearbox output sensor)

ABS and Chassis Codes

  • C1145: Front right wheel speed sensor input circuit failure
  • C1155: Front left wheel speed sensor input circuit failure
  • C1233: Speed wheel sensor front left input signal missing

Network Communication Codes

  • U1147: SCP (Standard Corporate Protocol) invalid or missing data for vehicle state
  • U1262: SCP (J1850) communication bus fault / engine to instrument cluster link error

Body Control Codes

  • B1318: Battery voltage low (detected by Central Timer Module / PATS module)
  • B1600: PATS (Passive Anti-Theft System) ignition key transponder signal not received

And thousands of additional diagnostic codes, test procedures, wiring diagrams, and repair instructions.

This manual is ideal for:

  • Professional automotive workshops
  • Independent repair garages
  • Mobile mechanics
  • Automotive technicians
  • Vehicle owners performing DIY repairs
  • Automotive training institutions

If you are troubleshooting, maintaining, servicing, or repairing a 1997-2002 Ford Puma, this is the factory workshop manual you need.
Model Years covered;
  • 1997 Ford Puma
  • 1998 Ford Puma
  • 1999 Ford Puma
  • 2000 Ford Puma
  • 2001 Ford Puma
  • 2002 Ford Puma
