1997-2003 Ford F150 Service and Repair Manual

This 1997-2003 Ford F150 Service and Repair Manual Covers

Engine and Drivetrain

• Procedures for 4.2L Essex V6, 4.6L Triton V8, and 5.4L Triton V8 (including supercharged SVT Lightning) engines.
• Sequential electronic fuel injection diagnostics, coil-on-plug (COP) ignition, and plug wire troubleshooting.
• Overhead camshaft (OHC) timing chain, tensioner, and guide replacement workflows.
• Engine cooling system, mechanical fan clutch, heater core bypass hoses, and water pump servicing.
• Exhaust manifold, EGR system, DPFE sensor diagnostics, and catalytic converter repairs.
• Overhaul for 5-speed manual (M5OD-R2), 4-speed automatic (4R70W), and heavy-duty 4-speed automatic (4R100) transmissions.
• Driveshafts, universal joints, front axle vacuum disconnect system, and transfer case (BorgWarner 4406 manual/electronic shift) service.

Chassis and Suspension

• Front independent torsion bar suspension repair procedures for 4WD models.
• Front independent coil spring and short-and-long-arm (SLA) suspension servicing for 2WD models.
• Rear leaf spring suspension, shackle brackets, hangers, and shock absorber replacement.
• Hydraulic power steering pump, steering gear box, and pitman/idler arm linkage troubleshooting.
• Wheel alignment specifications including caster, camber, and toe adjustment tracking.
• Front tapered wheel bearing repacking (2WD) and sealed hub unit replacement (4WD).

Braking Systems

• ABS module diagnostics, hydraulic control unit, and wheel speed sensor testing.
• Brake master cylinder replacement, vacuum brake booster adjustments, and electronic brake-force distribution.
• Front brake disc caliper, rotor, and rear disc brake assembly configurations (standard rear discs introduced 1999).
• Rear drum brake shoe replacement and drum machining specifications (early models).
• Mechanical foot-pedal parking brake assembly, internal drum-in-hat shoe service, and tension cable adjustment.

Electrical and Wiring

• Full factory wiring diagrams, harness routing, and ground terminal locations.
• 12V charging system diagnostics, alternator internal regulator setups, and starter motor diagnostics.
• EEC-V (OBD2) powertrain control module pinout schematics.
• Generic Electronic Module (GEM) and Central Security Module (CSM) diagnostics.
• Engine bay power distribution box and passenger compartment fuse panel layouts.
• Aero halogen headlamps, dashboard instrumentation clusters, and digital odometer odometer screen repair.

Air Conditioning and HVAC

• Manual or automatic climate control system diagnostics.
• R-134a refrigerant capacities, oil charge, and system pressure capacities.
• Blower motor resistor, heater core, and vacuum-operated blend door motor replacement.
• A/C compressor clutch clearance adjustments and low/high-pressure switch testing.

Body and Interior

• Regular cab, SuperCab (with rear access doors), and SuperCrew cab interior trim panels, seats, and headliner removal.
• Exterior steel body panel alignment, door hinges, tailgate latches, and stepside bed panel servicing.
• Power door locks, power window regulator motors, and remote keyless entry programming.
• Front driver and passenger SRS airbag module, clockspring, and passenger airbag deactivation switch service.

Diagnostics and Troubleshooting

• Diagnostic Trouble Code (DTC) lookup workflows for OBD2 systems.
• Ford New Generation Star (NGS) tester and standard OBD2 scan tool data workflows.
• Sensor voltage, resistance, and reference signal specifications (MAF, TPS, DPFE, O2 sensors).
• Step-by-step troubleshooting workflows for engine misfires under load, rough idle, or transmission slip.
• Fuel pump relay testing and inertia safety switch reset procedures.

Common Error Codes Covered

This manual provides diagnostic and repair procedures for thousands of manufacturer-specific fault codes, including:

Engine Codes

• P0300 – Random Cylinder Misfire Detected
• P0171 – System Too Lean Bank 1
• P0401 – Exhaust Gas Recirculation (EGR) Flow Insufficient (Common DPFE fault)
• P1280 – Injection Control Pressure Out of Range
• P0128 – Coolant Thermostat Error

Transmission Codes

• P0715 – Input/Turbine Speed Sensor Circuit Malfunction
• P0751 – Shift Solenoid A Performance or Stuck Off
• P1747 – Pressure Control Solenoid A Short Circuit

ABS and Chassis Codes

• C0020 – ABS Pump Motor Control Circuit Malfunction
• C0031 – Front Wheel Speed Sensor Signal Malfunction
• C1102 – Rear ABS Hydraulic Valve Circuit Malfunction

Network and Electronic Module Codes

• U1000 – SCP Network Class B Communication Bus Fault
• U1262 – SCP Communication Bus Fault (Cluster/GEM Error)

Body Control Codes

• B1311 – Clock Driver Circuit Open
• B1869 – Airbag Indicator Light Circuit Open or Short to Ground

And thousands of additional diagnostic codes, test procedures, wiring diagrams, and repair instructions.

• Professional automotive workshops
• Independent repair garages
• Mobile mechanics
• Automotive technicians
• Vehicle owners performing DIY repairs
• Automotive training institutions
