2008 Audi A5 Service and Repair Manual

This 2008 Audi A5 Service and Repair Manual Covers

Engine & Drivetrain

• 1.8L TFSI turbocharged petrol engine service and repair (selected markets)
• 3.2L FSI V6 petrol engine servicing
• 2.7L TDI V6 diesel engine servicing (selected markets)
• 3.0L TDI V6 diesel engine repair procedures
• Fuel injection and ignition system diagnostics
• Turbocharger diagnostics (diesel engines)
• Engine cooling system servicing
• Engine lubrication system repairs
• Exhaust and emissions control system diagnostics
• 6-speed manual transmission servicing
• Multitronic CVT servicing (front-wheel-drive models)
• 6-speed Tiptronic automatic transmission servicing
• quattro permanent all-wheel drive system servicing
• Torsen centre differential, propeller shaft, rear differential, and CV joint repairs

Braking Systems

• Hydraulic brake system servicing
• Anti-lock Braking System (ABS) diagnostics
• Electronic Stability Program (ESP) diagnostics
• Electronic Parking Brake (EPB) servicing
• Brake Assist system diagnostics
• Brake pad, brake disc, and caliper replacement procedures
• Brake hydraulic system bleeding

Chassis & Suspension

• Front five-link suspension repairs
• Rear trapezoidal-link suspension servicing
• Standard and Sport suspension servicing
• Audi Drive Select diagnostics (where equipped)
• Hydraulic and electro-mechanical steering diagnostics
• Wheel alignment specifications
• Wheel bearing replacement procedures
• Suspension component inspection and troubleshooting

Electrical & Wiring

• Complete factory wiring diagrams
• Battery, charging, and starting system diagnostics
• CAN Bus, LIN Bus, and MOST communication diagnostics
• Gateway control module diagnostics
• Body Control Module (BCM) diagnostics
• Instrument cluster diagnostics
• Audi MMI 2G/3G diagnostics (market dependent)
• Bluetooth® phone preparation diagnostics (where equipped)
• Audi Music Interface (AMI) diagnostics (where equipped)
• Bi-Xenon headlamp diagnostics (where equipped)

Air Conditioning & HVAC

• Single, dual-zone, and three-zone automatic climate control diagnostics (model dependent)
• Air conditioning compressor servicing
• Refrigerant recovery and recharge procedures
• HVAC control module diagnostics
• Heating and ventilation system repairs

Body & Interior

• Interior trim removal and installation
• Dashboard servicing procedures
• Door control module diagnostics
• Power window and central locking repairs
• Exterior lighting system servicing
• Airbag and occupant restraint system diagnostics
• Electrically adjustable and heated seat repairs (where equipped)
• Body panel alignment and repair information

Driver Assistance Systems

Available equipment varies by market and trim level.

• Audi Drive Select diagnostics (where equipped)
• Adaptive Cruise Control diagnostics (where equipped)
• Audi Side Assist (Blind Spot Monitoring) diagnostics (where equipped)
• Parking System Plus diagnostics
• Front and rear parking sensor diagnostics
• Rear-view camera diagnostics (where equipped)
• Adaptive headlight system diagnostics (where equipped)

Diagnostics & Troubleshooting

• VAS factory diagnostic procedures
• Guided fault-finding routines
• Diagnostic Trouble Code (DTC) lookup procedures
• ECU coding and adaptation procedures
• Control module programming support
• Sensor and actuator testing
• Step-by-step troubleshooting workflows

Common Error Codes Covered

This manual includes diagnostic procedures for common Audi fault codes applicable to the 2008 Audi A5.

Engine Codes

• P0087 – Fuel Rail/System Pressure Too Low
• P0171 – System Too Lean (Bank 1)
• P0299 – Turbocharger Underboost Condition (diesel models)
• P0300 – Random/Multiple Cylinder Misfire Detected
• P0401 – Exhaust Gas Recirculation Flow Insufficient Detected (diesel models)

Transmission Codes

• P0706 – Transmission Range Sensor Circuit Range/Performance
• P0726 – Engine Speed Input Circuit Range/Performance
• P0746 – Pressure Control Solenoid Performance (automatic models)

ABS & Chassis Codes

• C0031 – Left Front Wheel Speed Sensor Fault
• C1146 – Steering Angle Sensor Calibration Fault
• C10AC – Electronic Parking Brake Malfunction

Network Communication Codes

• U0100 – Lost Communication with Engine Control Module
• U0155 – Lost Communication with Instrument Cluster

Body Control Codes

• B2000 – Control Module Internal Malfunction
• B1263 – Rain and Light Sensor Fault
• B11CF – Interior Lighting Circuit Fault

The manual also includes hundreds of manufacturer-specific diagnostic trouble codes, factory wiring diagrams, ECU coding procedures, guided diagnostics, component testing specifications, and repair instructions.

Who Is This Manual For?

• Professional automotive workshops
• Audi dealership technicians
• Independent repair garages
• Mobile mechanics
• Automotive engineering students
• DIY enthusiasts

If you are servicing, maintaining, diagnosing, or repairing a 2008 Audi A5, this factory workshop manual provides the detailed repair procedures, wiring diagrams, technical specifications, diagnostic information, and repair procedures required to maintain the vehicle to Audi factory standards.
