2012-2013 Ford Everest Service and Repair Manual(Diesel)

This 2012-2013 Ford Everest Service and Repair Manual Covers

Engine and Drivetrain

• Complete repair procedures for the 2.5L TDCi and 3.0L TDCi Duratorq inline-4 turbo diesel engines.
• Common rail direct injection (CRDi) system diagnostics and fuel calibration.
• Turbocharger assembly, variable geometry turbocharger (VGT) actuation, and intercooler servicing.
• Exhaust gas recirculation (EGR) system cleanup and diesel particulate emissions repairs.
• Overhaul and troubleshooting for the 5-speed manual and 5-speed automatic transmissions.
• BorgWarner transfer case, 4×4 control module, front locking hubs, and propeller shaft service.

• Front independent double-wishbone suspension with torsion bar repair procedures.
• Rear leaf-spring suspension, shackle replacement, and shock absorber servicing.
• Hydraulic power-assisted steering rack and power steering pump troubleshooting.
• Wheel alignment specifications and mechanical adjustment procedures.
• Front and rear wheel bearing press-in replacement procedures.
• Suspension bush diagnostics, stabilizer bars, and ball joint replacement.

• Anti-lock Braking System (ABS) diagnostic and module bleeding procedures.
• Brake master cylinder, vacuum booster, and load-sensing proportioning valve (LSPV) service.
• Electronic Brakeforce Distribution (EBD) validation testing workflows.
• Center-console mechanical parking brake linkage adjustments.
• Front ventilated disc calipers and heavy-duty rear drum brake shoe replacement.

• Full factory wiring diagrams, harness routing, and splice block locations.
• Dual 12V battery configurations, high-output alternator testing, and starter motor diagnostics.
• Generic Electronic Module (GEM) programming and body network troubleshooting.
• Engine bay auxiliary relay boxes and internal fuse panel schematics.
• Halogen headlamp circuit routing and instrument cluster illumination repair.
• Factory audio units, parking sensor modules, and accessory socket wiring.

• Front and rear dual-compressor climate control system diagnostics.
• Front blower motor resistor and rear roof-mounted HVAC unit component replacement.
• R-134a refrigerant capacities and system manifold gauge troubleshooting.
• Mechanical compressor clutch adjustments and vacuum blend door troubleshooting.

• 3-row 7-seat configuration interior trim panel removal and installation.
• Side-opening rear tailgate door hinge alignment and external spare tire carrier bracing.
• Central locking actuators, keyless remote receiver programming, and perimeter alarm diagnostics.
• Power window regulator tracking and motor replacement workflows.
• SRS airbag deployment modules, crash sensors, and clockspring assembly replacement.

• Diagnostic Trouble Code (DTC) manufacturer-specific lookup tables.
• Ford IDS scan tool data stream monitoring and component calibration.
• Glow plug relay circuit and fuel pressure sensor testing specifications.
• Step-by-step diagnostic workflows for diesel engine hunting, hard starts, or black smoke.
• Control module parameter identification (PID) logging and module adaptations.

Common Error Codes Covered

This manual provides diagnostic and repair procedures for thousands of manufacturer-specific fault codes, including:

• P0201 – Injector Circuit Malfunction – Cylinder 1
• P0404 – Exhaust Gas Recirculation (EGR) Control Circuit Range/Performance
• P0234 – Turbocharger Overboost Condition
• P0088 – Fuel Rail/System Pressure – Too High
• P0380 – Glow Plug/Heater Circuit “A” Malfunction

• P0750 – Shift Solenoid “A” Malfunction
• P0741 – Torque Converter Clutch Circuit Performance or Stuck Off
• P0735 – Gear 5 Incorrect Ratio

• C0020 – ABS Pump Motor Control Circuit Malfunction
• C0031 – Left Front Wheel Speed Sensor Malfunction
• C1277 – Steering Wheel Angle Sensor Circuit Failure

• U0100 – Lost Communication With ECM/PCM
• U0140 – Lost Communication With Body Control Module

• B1311 – Clock Driver Circuit Open
• B2290 – Occupant Classification System Fault

And thousands of additional diagnostic codes, test procedures, wiring diagrams, and repair instructions.

• Professional automotive workshops
• Independent repair garages
• Mobile mechanics
• Automotive technicians
• Vehicle owners performing DIY repairs
• Automotive training institutions

If you are troubleshooting, maintaining, servicing, or repairing a 2012-2013 Ford Everest Diesel, this is the factory workshop manual you need.

This manual applies to the following model years;

2012 Ford Everest Service and Repair Manual(Diesel)
2013 Ford Everest Service and Repair Manual(Diesel)
