2013-2015 Ford Fiesta Service and Repair Manual

This 2013-2015 Ford Fiesta Service and Repair Manual Covers

Engine and Drivetrain

• 1.6L Ti-VCT 4-cylinder base engine overhauls, mechanical timing configurations, and cylinder head specifications
• 1.6L EcoBoost Turbocharged 4-cylinder (Fiesta ST) engine block assembly, overboost settings, and high-pressure direct injection testing
• 1.0L EcoBoost 3-cylinder engine mechanical variations, split-cooling setups, and wet-lubricated timing belt servicing
• Fuel injection system diagnostics, fuel pressure rail testing, and electronic throttle body adaptations
• Engine cooling system parameters, water pump rebuilds, and electronic thermostat housing diagnostic tests
• Exhaust and emissions control components, catalytic converter checking, and heated oxygen sensor (HO2S) monitoring
• IB5 5-speed manual transmission linkages, clutch assembly replacements, and hydraulic slave cylinder service
• B6 6-speed manual transmission overhauls, internal gear sets, and exact torque specifications for performance variants
• DPS6 PowerShift 6-speed dual-clutch automatic transmission fluid replacement, clutch pack renewals, and TCM programming
• Front-wheel-drive CV axle shaft installations, constant velocity boot repairs, and intermediate carrier bearings

Chassis and Suspension

• MacPherson strut front suspension subframe structures, coil spring removal, and lower control arm ball joint press procedures
• Twist-beam rear axle suspension bushings, rear shock absorber adjustments, and coil spring configurations
• Electric Power-Assisted Steering (EPAS) steering rack assemblies, column motor diagnostics, and software calibrations
• Wheel alignment factory specifications, front toe tracking adjustments, and rear geometric checking parameters
• Front wheel bearing hub assemblies and rear integrated bearing hub assembly press replacement setups

Braking Systems

• ABS hydraulic control unit modulator valve blocks, wheel speed sensor rings, and module configuration setups
• Traction Control System (TCS) and Electronic Stability Control (ESC) active yaw sensor calibrations
• Brake master cylinder overhauls, vacuum power booster checking, and precise low-pressure brake line fluid bleeding
• Mechanical handbrake cable tension setups, interior lever adjustments, and rear caliper mechanical parking actuators
• Front and rear solid or ventilated braking disc rotor wear limits and caliper slider pin cleaning procedures

Electrical and Wiring

• Complete factory electrical wiring schematics, grounding block pathways, and multi-pin harness layouts
• SmartShield electronic engine immobilizer and anti-theft security system transponder key programming
• Engine bay high-current fuse boxes, passenger compartment BCM fuse grids, and power distribution schematics
• Body Control Module (BCM) configuration adaptations, central locking actuators, and power window motor relays
• SYNC and SYNC with MyFord Touch infotainment system multi-wiring architectures, steering controls, and rear camera paths
• Reverse parking assist module circuitry, ultrasonic sonar sensor checking, and acoustic alert diagnostics

Air Conditioning and HVAC

• Manual dial-control configurations and Electronic Automatic Temperature Control (EATC) logic system diagnostics
• HVAC air blend door actuator motor replacements and dashboard air duct temperature sensor circuits
• R134a refrigerant capacities, compressor clutch tracking, and high-low system pressure charts
• Heater core swap workflows, cabin micro-filter replacement intervals, and multi-speed blower motor resistors

Body and Interior

• Interior door trim panel removal steps, center floor console assemblies, and headliner card installations
• Front seat track slide adjustments, manual frame repairs, and optional heated seat circuit grids
• Bonnet, boot lid, and hatchback tailgate hinge alignment margins and rubber weatherstripping paths
• External front and rear bumper fascia skins, side skirt fixtures, and headlight beam leveling specs
• Supplemental Restraint System (SRS) clocksprings, front airbags, side curtain airbags, and seatbelt pretensioners

Diagnostics and Troubleshooting

• Ford Integrated Diagnostic System (IDS) software scan tool pinpoint test pathways
• OBD2 diagnostic data link connector pin allocations and real-time live parameter ID (PID) data logging
• Fuel rail pressure mechanical testing, engine cylinder compression baselines, and smoke-tested vacuum leak detection
• Systematic engine crank but no-start troubleshooting logic trees

Common Error Codes Covered

This manual provides diagnostic and repair procedures for thousands of Ford-specific fault codes, including:

Engine Codes

• P0128: Coolant Thermostat Coolant Temperature Below Thermostat Regulating Temperature
• P0011 / P0012: Intake Camshaft Position Timing Over-Advanced / Over-Retarded
• P0300 – P0304: Random or Individual Cylinder Misfires Detected
• P0171 / P0174: System Too Lean Bank 1 / Bank 2
• P0420: Catalyst System Efficiency Below Threshold Bank 1

Transmission Codes

• P0700: Transmission Control System Malfunction Indicator Lamp Request
• P07A3: Transmission Friction Element A Stuck On (DPS6 automatic PowerShift clutch diagnostics)
• P0805: Clutch Position Sensor Circuit Malfunction

ABS and Chassis Codes

• C0031 / C0034: Left Front / Right Front Wheel Speed Sensor Sensor Circuit Faults
• C0051: Steering Wheel Angle Sensor Circuit Malfunction
• C1A00: Control Module General Electrical Failure

Network Communication Codes

• U0100: Lost Communication With Powertrain Control Module (PCM)
• U0101: Lost Communication With Transmission Control Module (TCM)
• U0140: Lost Communication With Body Control Module (BCM)

Body Control Codes

• B10A2: Crash Input Circuit Malfunction (SRS safety deployment logs)
• B1108: Driver Door Central Locking Actuator Malfunction

And thousands of additional diagnostic codes, test procedures, wiring diagrams, and repair instructions.

• Professional automotive workshops
• Independent repair garages
• Mobile mechanics
• Automotive technicians
• Vehicle owners performing DIY repairs
• Automotive training institutions
