2016 Audi A4 Service and Repair Manual

This 2016 Audi A4 Service and Repair Manual Covers:

Engine & Drivetrain

• 1.4L TFSI petrol engine service and repair (B9 markets)
• 2.0L TFSI turbocharged petrol engine servicing
• 1.4L TDI diesel engine servicing (selected markets)
• 2.0L TDI turbo diesel engine repair procedures
• 3.0L TDI V6 engine servicing (quattro models)
• Fuel injection and turbocharger diagnostics
• Engine cooling system servicing
• Engine lubrication system repairs
• Exhaust and emissions control system diagnostics
• Start/Stop system diagnostics (where equipped)
• 6-speed manual transmission servicing
• 7-speed S tronic dual-clutch transmission diagnostics and repair
• Multitronic CVT servicing (selected front-wheel-drive B8 markets)
• 8-speed Tiptronic automatic transmission servicing (quattro models)
• quattro all-wheel drive system servicing
• Centre differential, rear differential, driveshaft, and CV joint repairs

Braking Systems

• Hydraulic brake system servicing
• Anti-lock Braking System (ABS) diagnostics
• Electronic Stability Control (ESC) diagnostics
• Electronic Parking Brake (EPB) servicing
• Auto Hold system diagnostics
• Brake Assist system diagnostics
• Brake pad, disc, and caliper replacement procedures
• Brake hydraulic system bleeding

Chassis & Suspension

• Front five-link suspension repairs
• Rear five-link suspension servicing
• Dynamic suspension diagnostics (where equipped)
• Adaptive damping suspension servicing (where equipped)
• Dynamic steering diagnostics (where equipped)
• Wheel alignment specifications
• Wheel bearing replacement procedures
• Suspension component inspection and troubleshooting

Electrical & Wiring

• Complete factory wiring diagrams
• Battery Energy Management (BEM) diagnostics
• CAN Bus, LIN Bus, FlexRay, and MOST communication diagnostics
• Gateway control module diagnostics
• Body Control Module (BCM) diagnostics
• Instrument cluster diagnostics
• Audi Virtual Cockpit diagnostics (B9 models where equipped)
• Audi MMI and Navigation Plus diagnostics
• Bluetooth®, USB, Audi smartphone interface, and multimedia diagnostics
• Xenon, LED, and Matrix LED headlamp diagnostics (where equipped)

Air Conditioning & HVAC

• Single, dual-zone, and three-zone climate control diagnostics (model dependent)
• Air conditioning compressor servicing
• Refrigerant recovery and recharge procedures
• HVAC control module diagnostics
• Air quality sensor testing
• Heating and ventilation system repairs

Body & Interior

• Interior trim removal and installation
• Dashboard servicing procedures
• Door control module diagnostics
• Power window and central locking repairs
• Power tailgate diagnostics (Avant models where equipped)
• Exterior lighting system servicing
• Airbag and occupant restraint system diagnostics
• Electrically adjustable and memory seat repairs (where equipped)
• Body panel alignment and repair information

Driver Assistance Systems

• Audi Pre Sense City diagnostics (B9 models where equipped)
• Adaptive Cruise Control diagnostics (where equipped)
• Audi Active Lane Assist diagnostics (where equipped)
• Audi Side Assist diagnostics (where equipped)
• Parking System Plus diagnostics
• Rear-view camera diagnostics (where equipped)
• Front camera calibration procedures (B9 models where equipped)
• Radar sensor calibration (where equipped)

Diagnostics & Troubleshooting

• ODIS factory diagnostic procedures
• Guided fault-finding routines
• Diagnostic Trouble Code (DTC) lookup procedures
• ECU coding and adaptation procedures
• Software update procedures
• Component protection diagnostics
• Sensor and actuator testing
• Step-by-step troubleshooting workflows

Common Error Codes Covered

This manual includes diagnostic procedures for common Audi fault codes applicable to the 2016 Audi A4.

Engine Codes

• P0299 – Turbocharger Underboost Condition
• P0171 – System Too Lean (Bank 1)
• P0300 – Random/Multiple Cylinder Misfire Detected
• P00AF – Turbocharger Boost Control Module Performance
• P0401 – Exhaust Gas Recirculation Flow Insufficient Detected (diesel models)

Transmission Codes

• P0726 – Engine Speed Input Circuit Range/Performance
• P1735 – S tronic Clutch Adaptation Fault
• P17BF – Hydraulic Pump Protection Fault

ABS & Chassis Codes

• C0031 – Left Front Wheel Speed Sensor Fault
• C10AC – Electronic Parking Brake Malfunction
• C1146 – Steering Angle Sensor Calibration Fault

Network Communication Codes

• U0100 – Lost Communication with ECM/PCM
• U1113 – Function Restriction Due to Missing Message
• U1123 – Data Bus Communication Fault

Body Control Codes

• B2000 – Control Module Internal Malfunction
• B1263 – Rain and Light Sensor Fault
• B11CF – Interior Lighting Circuit Fault

The manual also includes hundreds of manufacturer-specific diagnostic trouble codes, wiring diagrams, ECU coding procedures, guided diagnostics, component testing specifications, and repair information.

Who Is This Manual For?

• Professional automotive workshops
• Audi dealership technicians
• Independent repair garages
• Mobile mechanics
• Automotive engineering students
• DIY enthusiasts with professional diagnostic equipment

If you are servicing, maintaining, diagnosing, or repairing a 2016 Audi A4, this factory workshop manual provides the detailed repair procedures, wiring diagrams, technical specifications, and diagnostic information required to perform repairs accurately and to Audi factory standards.
