2017 Audi R8 V10 Spyder Plus Service and Repair Manual

This 2017 Audi R8 V10 Spyder Plus Service and Repair Manual Covers

Engine & Drivetrain

• 5.2L Naturally Aspirated FSI V10 Plus engine (610 PS)
• Bosch MED engine management system diagnostics
• Fuel injection and ignition system servicing
• Audi Valvelift System (AVS) diagnostics
• Engine cooling and lubrication system servicing
• Exhaust and emissions control system repairs
• 7-Speed S tronic dual-clutch transmission diagnostics and repair
• quattro permanent all-wheel drive system
• Front and rear differential servicing
• Driveshaft and axle repairs

Chassis & Suspension

• Audi Magnetic Ride diagnostics
• Double wishbone front and rear suspension
• Electronic damping control
• Dynamic steering diagnostics (where equipped)
• Steering system servicing
• Wheel alignment specifications
• Suspension component inspection and replacement
• Wheel bearing servicing

Braking Systems

• High-performance braking system
• Anti-lock Braking System (ABS)
• Electronic Stability Control (ESC)
• Electronic Brakeforce Distribution (EBD)
• Brake Assist system diagnostics
• Carbon ceramic brake servicing (where equipped)
• Brake hydraulic system maintenance

Electrical & Wiring

• Complete factory wiring diagrams
• CAN Bus diagnostics
• Charging and starting system diagnostics
• Body Control Module (BCM)
• Power distribution, fuse, and relay assignments
• Audi Virtual Cockpit diagnostics
• MMI Navigation Plus infotainment system
• Exterior and interior lighting diagnostics

Convertible Roof System

• Electro-hydraulic soft-top diagnostics
• Roof control module servicing
• Roof latch adjustment procedures
• Hydraulic system inspection and repair
• Convertible roof alignment procedures
• Water leak diagnosis

Air Conditioning & HVAC

• Automatic climate control diagnostics
• HVAC control module servicing
• Refrigerant recovery and recharge procedures
• Heating and ventilation system repairs

Body & Interior

• Advanced Key (keyless entry and start)
• Power seat adjustment systems
• Door locking and window control diagnostics
• Interior trim removal and installation
• Exterior body repair procedures
• Airbag (SRS) system diagnostics

Diagnostics & Troubleshooting

• Audi ODIS diagnostic procedures
• Guided Fault Finding (GFF)
• Diagnostic Trouble Code (DTC) troubleshooting
• Control module coding and adaptations
• Component testing procedures
• System calibration following repairs

Common Error Codes Covered

This manual provides diagnostic and repair procedures for common Audi manufacturer-specific fault codes, including:

Engine Codes

• P0016 – Crankshaft/Camshaft Correlation
• P0106 – Manifold Absolute Pressure Sensor Range/Performance
• P0300 – Random/Multiple Cylinder Misfire
• P0420 – Catalyst System Efficiency Below Threshold (Bank 1)
• P0507 – Idle Speed Higher Than Expected

Transmission Codes

• P17D8 – S tronic Clutch Adaptation Fault
• P0726 – Engine Speed Input Circuit Performance
• P17BF – Transmission Control System Malfunction

ABS & Chassis Codes

• C1046 – Steering Angle Sensor Calibration Required
• C102D – Wheel Speed Sensor Fault
• C11A7 – Suspension Damping Control Fault

Network Communication Codes

• U0100 – Lost Communication With ECM/PCM
• U1113 – Function Restriction Due to Communication Fault
• U1121 – Missing Message on Data Bus

Body & Convertible Roof Codes

• B129C – Convertible Roof Position Sensor Fault
• B13AF – Roof Control Module Communication Fault
• B2000 – Body Control Module Internal Fault

The manual also includes hundreds of additional Audi-specific diagnostic trouble codes, guided diagnostic routines, wiring diagrams, module coding procedures, and factory repair instructions.

Who Is This Manual For?

• Audi dealership technicians
• Independent European vehicle repair workshops
• Performance vehicle specialists
• Automotive technicians
• Exotic and supercar service centres
• Experienced DIY mechanics

If you are servicing, maintaining, diagnosing, or repairing a 2017 Audi R8 V10 Spyder Plus, this factory workshop manual provides the complete procedures and technical information required to perform repairs to Audi factory standards.
